2.7M130
September 23, 2024The Senvion
2xm Series
Our 2MW M120 series wind turbine, which has a hub height of 120m, has been optimised for higher yields at medium wind sites. With an operating temperature range of up to 50 °C, it can also be used in tropical climates. The Senvion 2MW series meets all the Indian grid code requirements.
| Nominal Power(KW) | 2330 |
| Cut in wind speed (m/s) | 3.0 |
| Cut out wind speed (m/s) | 20.0 |
| Nominal wind speed (m/s) | 11.0 |
| Operating Temperature range (°C) | -10 to +40 |
| Survival Temperature range (°C) | -20 to +50 |
| Nominal Power(Hz) | 50 |
| Converter type | Full power conversion with IGBT |
| Generator | Electrically excited synchronous generator |
| Generator protection class | IP 54 |
| Wind Class | IEC S |
| Type Testing | IECS 61400-22 |
| Diameter (m) | 120.0 |
| Rotor area (m2) | 11,310 |
| Power Control | Electrical pitch system |
| Length (m) | 58.7 |
| Profile Type | LM 58.7 |
| Material | GFRP |
| Type | Tubular steel tower |
| Height | 120m |
