3mw Series
Our new 3MW+ series wind turbine generator with a hub height of 130m has been optimized for higher yields at medium - low wind site. With an operating temperature range of upto 49 °C, it can also be operated in tropical climates. The supply chain is localized. The 3.XM series is fully compliant with Indian grid code requirement
| Nominal Power(KW) | 3100 |
| Cut in wind speed (m/s) | 3.0 |
| Cut out wind speed (m/s) | 20.0 |
| Nominal wind speed (m/s) | 12.0 |
| Operating Temperature range (°C) | -10 to 49 |
| Survival Temperature range (°C) | -20 to +50 |
| Nominal Power(Hz) | 50 |
| Converter type | Frequency converter for DFIG with DC Link |
| Generator | Double-fed induction generator (DFIG) |
| Generator protection class | IP 54 |
| Wind Class | IEC S |
| Type Testing | IEC 61400-22 |
| Diameter (m) | 130.0 |
| Rotor area (m2) | 13,273 |
| Power control | Electrical pitch system |
| Length (m) | 63.7 |
| Profile Type | SE 63.7 |
| Material | GFRP |
| Type | Tubular steel tower |
| Height | Up to 140m |
